Human Engineering Delivers User-Friendly Operation
An outboard designed with user-friendly features, is an outboard that lets you enjoy more of your time on the water. That's why this outboard motor is equipped with a twist-grip throttle for easier operation from different sitting positions, and full-turn 360° teering, which is advantageous when maneuvering in tight places and also delivers superior thrust when backing. Operation is quiet and smooth, and the engine is water-cooled for increased durability and dependability. And a large capacity integrated fuel tank holds one-liter of fuel, which provides an estimated operating time of almost an hour on a full tank. Other features include steering and throttle tension adjustor systems, F-N shifting located on the starboard side just where you'd expect, and an oil level indicator conveniently located on the port side for easy oil checks.
Ultra-Portable
Removed from the boat, this outboard motor is balanced, lightweight, and easy to manage due to its large carrying handle. The integrated handle is located on the back of the engine cowling where it also assists when tilting the engine. And there's four-position tilting for matching the outboard with individual boat and operating conditions.
Environmentally Friendly, Economical Operation
Suzuki's four-stroke technology squeezes more from every tank of fuel than a comparable two-stroke outboard. Four-stroke technology also delivers clean operation that allows this outboard motor to gain CARB 3-Star Certification for Ultra Low Emissions by the California Air Resources Board.
Specifications
| Recommended Transom Height (mm) |
S: 381, L: 508 |
| Weight (kg*) |
S: 13.5, L: 14 |
| Engine type |
OHV |
| Piston Displacement (cm³) |
68 |
| Maximum Output (kw) |
1.8 |
| Steering |
Tiller, 360° rotation |
| Recommended Fuel |
RON91 / AKI87 |
| Alternator |
- |
| Gear Ratio |
2.15 : 1 |
| Exhaust |
Above Prop Exhaust |
| Starting system |
Manual |
| Cylinders |
1 |
| Fuel Delivery System |
Carburetor |
| Bore X Stroke (mm) |
48 x 38 |
| Full Throttle Operating Range (rpm) |
5,250 - 5,750 |
| Oil Pan Capacity (L) |
0.38 |
| Fuel Tank Capacity (L) |
Integral 0.9 |
| Trim Method |
Manual Trim and Tilt |
| Gear Shift |
F-N |
| Propeller Selection (Pitch) |
5.3/8” |
